1/4 inch 3/8inch Panel Mount Back Pressure Valve Low Pressure
R71 Stainless Steel Pressure Regulator
Product Specification
| 1 | Single-stage configuration | |
| 2 | Body port | 1/4″ NPT(F) |
| 3 | 2″ Pressure Gauge | 1.5 times maximum inlet pressure |
| 4 | Temperature range | -40℉ to 165℉ (-40℃ to 74℃)℉ |
| 5 | Leak Rate | 2 x 10-8atm.cc/sec He |
| 6 | CV | 0.08 |
| 7 | Material | Stainless steel or Brass |
Features
*Body: 316L
*Seat: PCTFE, PTFE
*Diaphragm: 316L
Typical applications
*Process Control
*Laboratories
*Petrochemical industry
*Power plant equipments
| ORDERING INFORMATION | |||||||
| SERIES | BODY MATERIAL | BODY PORTS | INLET PRESSURE | GAUGES | INLET CONNECTION | OUTLET CONNECTION | Optional |
| RW71 | L | A | D | G | 02 | 02 | P |
| L: 316L
B: brass
|
A
B
|
G: 0-250Psi
I:0-100Psi
K:0-50Psi
L:0-25Psi
|
W: None
P: psi/bar
G: Mpa
|
00:1/4″NPT(F)
01:1/4″NPT(M)
10:1/8″ LOK
11:1/4″ LOK
12: 3/8″ LOK
|
00:1/4″NPT(F) 01:1/4″NPT(M) 10:1/8″ LOK 11:1/4″ LOK 12: 3/8″ LOK |
P: Panel
mounting
|
|
In solar cell applications specifically include solar cell applications, crystalline silicon solar cell production process and gas applications, thin film solar cell production process and gas applications; in compound semiconductor applications specifically include compound semiconductor applications, MOCVD / LED production process and gas applications; in liquid crystal display applications specifically include TFT / LCD applications, TFT In the application of liquid crystal display, it includes the application of TFT/LCD, the production process of TFT/LCD and gas application; in the application of optical fiber, it includes the application of optical fiber and the production process of fiber preform and gas application.
Q. Are you manufacturer?
A. Yes, we are manufacturer.
Q.What is lead time?
A.3-5days. 7-10 days for 100pcs
Q. How do I order?
A.You can order it from Alibaba directly or send us a inquiry. We will reply you within 24 hours
Q. Do you have any certificates?
A.We have CE certificate.
Q. What materials do you have?
A.aluminium alloy and chrome plated brass are available. The picture shown is chrome plated brass. If you need other material, pls contact us.
Q. What is maximum inlet pressure?
A.3000psi (about 206bar)
Q. How do I confirm inlet connnection for cylidner?
A. Pls check cylinder type and confirm it. Normally, it is CGA5/8 male for Chinese cylinder. Other cylidner adapter are also
available e.g CGA540, CGA870 etc.
Q. How many types for connecting cylinder?
A.Down way and side way. (you can choose it)
Q. What is product warranty?
A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
