Argon Co2 Weld Low Pressure Brass Pressure Regulator
R57L Brass Pressure Regulator
R57L series single pressure regulator which is used for small and medium flow gas distribution system and suitable for insert gases i.e Argon, Helium, Oxygen, Co2 etc.
Features of Structure
Single Stage pressure reducing pressure structure
2″Diaphragm
2″ pressure gauge
Max. inlet pressure 2. 5Mpa(25bar, 362. 5PSI)
Material
Body: Brass
Bonnet: Brass
Diaphragm: Neoprene
Stainer: Bronze
Application
Non-corrosive gas
Purge System
Laboratory test
Industrial Manufacture
|
Model NO |
Medium |
Max. inlet P. |
Oulet P. |
Inlet gauge |
Outlet gauge |
Inlet connection |
Oulet connection |
|
R57LX-15 |
o2 |
2.5 |
0.03 ~ 0.85 |
N/A |
1.6 |
1/4” NPT(F) |
1/4” NPT(F) |
|
R57LX-15-N |
2.5 |
0.03 ~ 0.85 |
N/A |
1.6 |
M16-1.5RH(M) |
M16-1.5RH(M) |
|
|
R57LX-17-N |
2.5 |
0.03 ~ 1.7 |
N/A |
2.5 |
1/4” NPT(F) |
1/4”NPT(F) |
|
|
R57LY-15 |
acetylene |
2.5 |
0.01-0.1 |
N/A |
0.25 |
1/4” NPT(F) |
1/4″ NPT(F) |
|
R57LY-15-N |
2.5 |
0.01-0.1 |
N/A |
0.25 |
M16-1.5RH(M) |
M16-1.5RH(M) |
|
|
R57LF-8O |
propane.NG |
2.5 |
0.02 ~ 0.56 |
N/A |
1 |
1/4” NPT(F) |
1/4”NPT(F) |
|
R57LF-80-N |
2.5 |
0.02 ~ 0.56 |
N/A |
1 |
M16-1.5RH(M) |
M16-1.5RH(M) |
|
|
R57UN-15 |
Ar, He, N2 |
2.5 |
0.03 ~ 0.85 |
N/A |
1.6 |
1/4”NPT(F) |
1/4”NPT(F) |
|
R57UN-17 |
2.5 |
0.03 ~ 1.7 |
N/A |
2.5 |
1/4”NPT(F) |
1/4”NPT(F) |
|
|
R57LQ-15 |
Air |
2.5 |
0.03 ~ 0.85 |
N/A |
1.6 |
1/4”NPT(F) |
1/4”NPT(F) |
|
R57LQ-17 |
2.5 |
0.03 ~ 1.7 |
N/A |
2.5 |
1/4* NPT(F) |
1/4* NPT(F) |
|
|
R57LH-08 |
H2 |
2.5 |
0.02 ~ 0.85 |
N/A |
1 |
1/4”NPT(F) |
1/4”NPT(F) |
|
R57LH-15 |
2.5 |
0.03 ~ 0.85 |
N/A |
1.6 |
1/4* NPT(F) |
1/4* NPT(F) |
|
|
R57LH-17 |
2.5 |
0.03 ~ 1.7 |
N/A |
2.5 |
1/4″ NPT(F) |
1/4” NPT(F) |
|
|
R57LC-15 |
Co2 |
2.5 |
0.03 ~ 0.85 |
N/A |
1.6 |
1/4” NPT(F) |
1/4”NPT(F) |
|
R57LC-17 |
2.5 |
0.03 ~ 1.7 |
N/A |
2.5 |
1/4” NPT(F) |
1/4” NPT(F) |
